5.56x45mm AP
TUNGSTEN CARBIDE & LEAD CORE
BOXER
NON-MERCURIC
SPECIAL PURPOSE
5.56 x 45
MM AP
TUNGSTEN CARBIDE & LEAD CORE
Special-purpose ammunition engineered for
exceptional long-range accuracy and consistent reliability.
REQUEST A QUOTE → TUNGSTEN CARBIDE & LEAD CORE
BOXER
NON-MERCURIC
~4.10G63GR
BULLET WEIGHT
11.80G - 12.90G
CARTRIDGE WEIGHT
10YR
SHELF LIFE
TECHNICAL SPECIFICATIONS &
Performance Data
CASE MATERIAL
Brass CuZn30
·
PROPELLANT
Double/Single Base
·
PRIMER
Boxer
Non-corrosive
PROJECTILE DETAILS
Projectile Types
TYPE OF PROJECTILE
FMJ-AP
JACKET MATERIAL
Tombac CuZn10
CORE
Tungsten Carbide & Lead Core
JACKET MATERIAL
Tombac CuZn10
CORE
Lead & Antimony
WEIGHT
124 gr / 8 g
JACKET MATERIAL
Tombac CuZn10
CORE
Lead & Antimony
WEIGHT
124 gr / 8 g
JACKET MATERIAL
Tombac CuZn10
CORE
Lead & Antimony
WEIGHT
158 gr / 10.2 g
CARTRIDGE DETAILS
Dimensions & Weight
CARTRIDGE LENGTH
56.70mm - 57.40mm
CARTRIDGE WEIGHT
11.80g - 12.90g
CASE LENGTH
44.45mm-45.00mm
CASE WEIGHT
5.85g - 6.80g
BULLET LENGTH
20.60mm - 21.60mm
BULLET WEIGHT
~4.10g (63gr)
PART NUMBER
HPM19124
BLANK CASE
FMJ RN (124 gr)
VELOCITY V16 M/S
370 ± 10
PRESSURE AVG + 3*SD BAR
2850
WEIGHT
~12.1 g
PART NUMBER
HPM19124JHP
BLANK CASE
JHP (124 gr)
VELOCITY V16 M/S
370 ± 10
PRESSURE AVG + 3*SD BAR
2850
WEIGHT
~12.1 g
PART NUMBER
HPM19158SUB
BLANK CASE
Subsonic FMJ FN/RN (158 gr)
VELOCITY V16 M/S
290 ± 10
PRESSURE AVG + 3*SD BAR
2850
WEIGHT
~14.4 g
PART NUMBER
HPM19BL
BLANK CASE
Blank
WEIGHT
~5.4 g
TECHNICAL SPECIFICATIONS &
Characterstics
VELOCITY, AVERAGE
875 ± 15 m/s, at a muzzle at 21±2°C, using standard proof barrel of 500mm length
MEAN CHAMBER PRESSURE
Pavg max ≤ 4300 bar at 21±2°C, using standard proof barrel, EPVAT using 6215 piezoelectric transducer
FUNCTIONING
Cartridges function all specified weapons without casualty at ambient temperatures at -10°C and +63°C
ACCURACY TEST
Sa ≤ 25 mm at 300m from the muzzle end, using standard proof barrel of 650mm length
STORAGE TEMPERATURE
From -20°C to +70°C with daily temperature difference less than 10°C
PENETRATION EFFECT
Penetrate 5mm steel plate (480-530 HB) at 200m on steel plate
BULLET EXTRACTION FORCE, MINIMUM
≥ 200 N
OPERATING TEMPERATURE
-10°C to +63°C
SHELF LIFE
10 years
WATERPROOF
Cartridges are Waterproof (Bubbles Test)
MAXIMUM RANGE
3312 meters
CERTIFICTIONS &
Compliance Standards
